The SC95 sliding window and door system from AluK is a superior, high performing sliding solution with aesthetics and design appeal. The product comes with sturdy rollers tested for many cycles of operation and a trusted and proven AluK product worldwide for decades. This versatile sliding window solution comes with lot of choices and customized options and is an ideal lifetime sliding solution for tropical and hot climate applications in high-rise buildings, individual residences and commercial establishments.

Product features

  • SC95 sliding system is based on non-insulated profiles. The thermal break insulated profile option is available in SC95TT.
  • A 95 mm frame in two track and 143 mm frame in three track, single and double glazed slider with 85 mm interlock profile at centre. Slimmer option of 55 mm interlock is also available.
  • SC95 comes with a glazing bead based solution; hence convenience in glass interchangeability for users.
  • Superior aesthetics with international design appeal: 45 degree join for sashes and 90 degree join for frames.
  • Well-designed sloped bottom track with effective drainage solution.
  • Anodized rail on bottom track for extra smooth sliding.
  • Solid and robust in performance works for very high design wind pressure; a thoroughly tested window system for demanding weather criteria of tropical zones. A tested and certified product as per EN norms for air/water/wind.
  • Possibility of fixed light, flyscreen/casement integration.
  • All accessories, fittings, gaskets are AluK branded and tested for performance.
  • Value added features like perimeter gasket for added protection at edges of the window application surface.
  • Single, multipoint locking with flush spring locks, thumb pull lever locks or cremone handles for convenience of usage.
  • This system is adapted for large dimensions with sash weight up to 160 kg of load bearing capacity per sash.
  • Infill glass can be single or double glazed (thickness can vary from 6 to 24 mm).

Performances

  • Uw = 2 W/m²K (SC95TT)
  • Air: 4
  • Water: 8A
  • Wind: B2
  • Test based on a window of 2 Track 2 Sashes of W 2392 mm and H 2290 mm.

Applications

A wide range of sliding option is available with choice of integrated fly screen. System applications include:

  • 2 Track 2 sashes,
  • 2 Track 3 sashes,
  • 2 Track 4 sashes,
  • 3 Track 6 sashes,
  • Fixed lights in combination with sliding sashes
